12V9 150*20*31.75*10mm D30 C125 Resin Bond Diamond Grinding Wheel
Product Details
| Colour: | Green | Diameter: | 150mm |
|---|---|---|---|
| Thickness: | 20mm | Inner Hole: | 31.75mm |
| Abrasive Width: | 10mm | Base Material: | Aluminum Powder |
| Abrasive Material: | Diamond | Bond: | Resin |
| Grit: | D30 | Shape: | Cup |
| HS Code: | 6804211000 | Precision: | High |
| Diamond Class: | First Class | Application: | Carbide Grinding |
| Delivery: | By Express | ||
| Highlight |
C125 Resin Bond Diamond Grinding Wheel,12V9 Resin Bond Diamond Grinding Wheel,Resin Bond Diamond Grinding Wheel |
||
Product Description
12V9 150*31.75*10mm D30 C125 Resin Diamond Grinding Wheel Product Description
Product Name: Resin Grinding Wheel
Core composition:
Diamond abrasive: artificial or natural diamond particles, providing ultra-high hardness and wear resistance (Mohs hardness 10).
Resin binder: commonly used phenolic resin, polyimide (PI), epoxy resin, etc., which give the grinding wheel elasticity and facilitate heat dissipation.
Filler: aluminum powder, used to adjust the strength, thermal conductivity or wear resistance of the binder.
Product specification:
12V9 Indicates the wheel's shape (cup wheel) and abrasive structure,Common for precision grinding applications.
150mm: grinding wheel outer diameter (D)
20mm: grinding wheel thickness (T)
31.75mm: inner hole diameter (H)
10mm: abrasive width (W)
D30 : Diamond abrasive grit (G)
C125: Diamond concentration (C)
Of course, we can also customize other sizes for you.
Applications:
Processing materials: carbide tools, ceramic components, semiconductor materials, etc.
Applicable machine tools: tool grinders, cylindrical grinders, etc.
Payment and Shipping:
We accept various payment terms, including T/T, L/C, WesternUnion, and PayPal. Our standard packaging is carton, but we can also customize the packaging based on your requirements. The Resin Bond Grinding Wheel comes in a sturdy cardboard box with foam padding to ensure safe transport and storage. The product will be shipped via standard ground shipping and will be securely packaged to prevent any damage during transit. Delivery time may vary depending on the destination, but typically takes between 5-10 business days.
Company introduction:
We are the professional manufacturer of vitrified bond diamond grinding wheels, equipped with advanced production facilities and testing instruments. Our products are known for their stable and reliable quality, earning the trust of our customers. We are committed to providing high-quality products and services. Welcome to inquire and purchase.
